Tactical Graphic Status

This page lists all of the tactical graphics defined in MIL-STD-2525C, and shows which graphics are supported in World Wind.

Appendix B, Tactical Graphics

Hierarchy Description Supported
TACGRP.TSK.BLK Block
TACGRP.TSK.BRH Breach
TACGRP.TSK.BYS Bypass
TACGRP.TSK.CNZ Canalize
TACGRP.TSK.CLR Clear
TACGRP.TSK.CNT Contain
TACGRP.TSK.CATK Counterattack (CATK)
TACGRP.TSK.CATK.CATKF Counterattack By Fire
TACGRP.TSK.DLY Delay
TACGRP.TSK.DSTY Destroy Yes
TACGRP.TSK.DRT Disrupt
TACGRP.TSK.FIX Fix
TACGRP.TSK.FLWASS Follow And Assume
TACGRP.TSK.FLWASS.FLWSUP Follow And Support
TACGRP.TSK.ITDT Interdict Yes
TACGRP.TSK.ISL Isolate
TACGRP.TSK.NEUT Neutralize Yes
TACGRP.TSK.OCC Occupy
TACGRP.TSK.PNE Penetrate
TACGRP.TSK.RIP Relief In Place (RIP)
TACGRP.TSK.RTN Retain
TACGRP.TSK.RTM Retirement
TACGRP.TSK.SCE Secure
TACGRP.TSK.SEC Security
TACGRP.TSK.SEC.SCN Screen
TACGRP.TSK.SEC.GUD Guard
TACGRP.TSK.SEC.COV Cover
TACGRP.TSK.SZE Seize
TACGRP.TSK.WDR Withdraw
TACGRP.TSK.WDR.WDRUP Withdraw Under Pressure
TACGRP.C2GM.GNL.PNT.USW.UH2.DTM Datum Yes
TACGRP.C2GM.GNL.PNT.USW.UH2.BCON Brief Contact Yes
TACGRP.C2GM.GNL.PNT.USW.UH2.LCON Lost Contact Yes
TACGRP.C2GM.GNL.PNT.USW.UH2.SNK Sinker Yes
TACGRP.C2GM.GNL.PNT.USW.SNBY Sonobuoy Yes
TACGRP.C2GM.GNL.PNT.USW.SNBY.PTNCTR Pattern Center Yes
TACGRP.C2GM.GNL.PNT.USW.SNBY.DIFAR Directional Frequency Analyzing And Recording (DIFAR) Yes
TACGRP.C2GM.GNL.PNT.USW.SNBY.LOFAR Low Frequency Analyzing And Recording (LOFAR) Yes
TACGRP.C2GM.GNL.PNT.USW.SNBY.CASS Command Active Sonobuoy System (CASS) Yes
TACGRP.C2GM.GNL.PNT.USW.SNBY.DICASS Directional Command Active Sonobuoy System (DICASS) Yes
TACGRP.C2GM.GNL.PNT.USW.SNBY.BT Bathythermograph Transmitting (BT) Yes
TACGRP.C2GM.GNL.PNT.USW.SNBY.ANM Anm Yes
TACGRP.C2GM.GNL.PNT.USW.SNBY.VLAD Vertical Line Array DIFAR (VLAD) Yes
TACGRP.C2GM.GNL.PNT.USW.SNBY.ATAC Atac Yes
TACGRP.C2GM.GNL.PNT.USW.SNBY.RO Range Only (RO) Yes
TACGRP.C2GM.GNL.PNT.USW.SNBY.KGP Kingpin Yes
TACGRP.C2GM.GNL.PNT.USW.SNBY.EXP Sonobuoy-Expired Yes
TACGRP.C2GM.GNL.PNT.USW.SRH Search Yes
TACGRP.C2GM.GNL.PNT.USW.SRH.ARA Search Area Yes
TACGRP.C2GM.GNL.PNT.USW.SRH.DIPPSN DIP Position Yes
TACGRP.C2GM.GNL.PNT.USW.SRH.CTR Search Center Yes
TACGRP.C2GM.GNL.PNT.REFPNT Reference Point Yes
TACGRP.C2GM.GNL.PNT.REFPNT.NAVREF Navigational Reference Point Yes
TACGRP.C2GM.GNL.PNT.REFPNT.SPLPNT Special Point Yes
TACGRP.C2GM.GNL.PNT.REFPNT.DLRP Dlrp Yes
TACGRP.C2GM.GNL.PNT.REFPNT.PIM Point Of Intended Movement (Pim) Yes
TACGRP.C2GM.GNL.PNT.REFPNT.MRSH Marshall Point Yes
TACGRP.C2GM.GNL.PNT.REFPNT.WAP Waypoint Yes
TACGRP.C2GM.GNL.PNT.REFPNT.CRDRTB Corridor Tab Yes
TACGRP.C2GM.GNL.PNT.REFPNT.PNTINR Point Of Interest Yes
TACGRP.C2GM.GNL.PNT.WPN Weapon Yes
TACGRP.C2GM.GNL.PNT.WPN.AIMPNT Aim Point Yes
TACGRP.C2GM.GNL.PNT.WPN.DRPPNT Drop Point Yes
TACGRP.C2GM.GNL.PNT.WPN.ENTPNT Entry Point Yes
TACGRP.C2GM.GNL.PNT.WPN.GRDZRO Ground Zero Yes
TACGRP.C2GM.GNL.PNT.WPN.MSLPNT Msl Detect Point Yes
TACGRP.C2GM.GNL.PNT.WPN.IMTPNT Impact Point Yes
TACGRP.C2GM.GNL.PNT.WPN.PIPNT Predicted Impact Point Yes
TACGRP.C2GM.GNL.PNT.FRMN Formation Yes
TACGRP.C2GM.GNL.PNT.HBR Harbor (General) Yes
TACGRP.C2GM.GNL.PNT.HBR.PNTQ Point Q Yes
TACGRP.C2GM.GNL.PNT.HBR.PNTA Point A Yes
TACGRP.C2GM.GNL.PNT.HBR.PNTY Point Y Yes
TACGRP.C2GM.GNL.PNT.HBR.PNTX Point X Yes
TACGRP.C2GM.GNL.PNT.RTE Route Yes
TACGRP.C2GM.GNL.PNT.RTE.RDV Rendezvous Yes
TACGRP.C2GM.GNL.PNT.RTE.DVSN Diversions Yes
TACGRP.C2GM.GNL.PNT.RTE.WAP Waypoint Yes
TACGRP.C2GM.GNL.PNT.RTE.PIM Pim Yes
TACGRP.C2GM.GNL.PNT.RTE.PNTR Point R Yes
TACGRP.C2GM.GNL.PNT.ACTL Air Control Yes
TACGRP.C2GM.GNL.PNT.ACTL.CAP Combat Air Patrol (CAP) Yes
TACGRP.C2GM.GNL.PNT.ACTL.ABNEW Airborne Early Warning (AEW) Yes
TACGRP.C2GM.GNL.PNT.ACTL.TAK Tanking Yes
TACGRP.C2GM.GNL.PNT.ACTL.ASBWF Antisubmarine Warfare, Fixed Wing Yes
TACGRP.C2GM.GNL.PNT.ACTL.ASBWR Antisubmarine Warfare, Rotary Wing Yes
TACGRP.C2GM.GNL.PNT.ACTL.SUWF SUCAP – Fixed Wing Yes
TACGRP.C2GM.GNL.PNT.ACTL.SUWR SUCAP – Rotary Wing Yes
TACGRP.C2GM.GNL.PNT.ACTL.MIWF IW – Fixed Wing Yes
TACGRP.C2GM.GNL.PNT.ACTL.MIWR MIW – Rotary Wing Yes
TACGRP.C2GM.GNL.PNT.ACTL.SKEIP Strike Ip Yes
TACGRP.C2GM.GNL.PNT.ACTL.TCN Tacan Yes
TACGRP.C2GM.GNL.PNT.ACTL.TMC Tomcat Yes
TACGRP.C2GM.GNL.PNT.ACTL.RSC Rescue Yes
TACGRP.C2GM.GNL.PNT.ACTL.RPH Replenish Yes
TACGRP.C2GM.GNL.PNT.ACTL.UA Unmanned Aerial System (UAS/UA) Yes
TACGRP.C2GM.GNL.PNT.ACTL.VTUA Vtua Yes
TACGRP.C2GM.GNL.PNT.ACTL.ORB Orbit Yes
TACGRP.C2GM.GNL.PNT.ACTL.ORBF8 Orbit – Figure Eight Yes
TACGRP.C2GM.GNL.PNT.ACTL.ORBRT Orbit – Race Track Yes
TACGRP.C2GM.GNL.PNT.ACTL.ORBRD Orbit – Random, Closed Yes
TACGRP.C2GM.GNL.PNT.ACTPNT Action Points (General) Yes
TACGRP.C2GM.GNL.PNT.ACTPNT.CHKPNT Check Point Yes
TACGRP.C2GM.GNL.PNT.ACTPNT.CONPNT Contact Point Yes
TACGRP.C2GM.GNL.PNT.ACTPNT.CRDPNT Coordination Point Yes
TACGRP.C2GM.GNL.PNT.ACTPNT.DCNPNT Decision Point Yes
TACGRP.C2GM.GNL.PNT.ACTPNT.LNKUPT Linkup Point Yes
TACGRP.C2GM.GNL.PNT.ACTPNT.PSSPNT Passage Point Yes
TACGRP.C2GM.GNL.PNT.ACTPNT.RAYPNT Rally Point Yes
TACGRP.C2GM.GNL.PNT.ACTPNT.RELPNT Release Point Yes
TACGRP.C2GM.GNL.PNT.ACTPNT.STRPNT Start Point Yes
TACGRP.C2GM.GNL.PNT.ACTPNT.AMNPNT Amnesty Point Yes
TACGRP.C2GM.GNL.PNT.ACTPNT.WAP Waypoint Yes
TACGRP.C2GM.GNL.PNT.SCTL EA Surface Control Station Yes
TACGRP.C2GM.GNL.PNT.SCTL.USV Unmanned Surface Vehicle (USV) Control Station Yes
TACGRP.C2GM.GNL.PNT.SCTL.USV.RMV Remote Multimission Vehicle (RMV) Usv Control Station Yes
TACGRP.C2GM.GNL.PNT.SCTL.USV.ASW USV – Antisubmarine Warfare Control Station Yes
TACGRP.C2GM.GNL.PNT.SCTL.USV.SUW USV – Surface Warfare Control Station Yes
TACGRP.C2GM.GNL.PNT.SCTL.USV.MIW USV – Mine Warfare Control Station Yes
TACGRP.C2GM.GNL.PNT.SCTL.ASW ASW Control Station Yes
TACGRP.C2GM.GNL.PNT.SCTL.SUW SUW Control Station Yes
TACGRP.C2GM.GNL.PNT.SCTL.MIW MIW Control Station Yes
TACGRP.C2GM.GNL.PNT.SCTL.PKT Picket Control Station Yes
TACGRP.C2GM.GNL.PNT.SCTL.RDV Rendezvous Control Point Yes
TACGRP.C2GM.GNL.PNT.SCTL.RSC Rescue Control Point Yes
TACGRP.C2GM.GNL.PNT.SCTL.REP Replenishment Control Point Yes
TACGRP.C2GM.GNL.PNT.SCTL.NCBTT Noncombatant Control Station Yes
TACGRP.C2GM.GNL.PNT.UCTL Subsurface Control Station Yes
TACGRP.C2GM.GNL.PNT.UCTL.UUV Unmanned Underwater Vehicle (UUV) Control Station Yes
TACGRP.C2GM.GNL.PNT.UCTL.UUV.ASW UUV – Antisubmarine Warfare Control Station Yes
TACGRP.C2GM.GNL.PNT.UCTL.UUV.SUW UUV – Surface Warfare Control Station Yes
TACGRP.C2GM.GNL.PNT.UCTL.UUV.MIW UUV – Mine Warfare Control Station Yes
TACGRP.C2GM.GNL.PNT.UCTL.SBSTN Submarine Control Station Yes
TACGRP.C2GM.GNL.PNT.UCTL.SBSTN.ASW ASW Submarine Control Station Yes
TACGRP.C2GM.GNL.LNE.BNDS Boundaries Yes
TACGRP.C2GM.GNL.LNE.FLOT Forward Line Of Own Troops (FLOT) Yes
ACGRP.C2GM.GNL.LNE.LOC Line Of Contact Yes
TACGRP.C2GM.GNL.LNE.PHELNE Phase Line Yes
TACGRP.C2GM.GNL.LNE.LITLNE Light Line Yes
TACGRP.C2GM.GNL.ARS.GENARA General Area Yes
TACGRP.C2GM.GNL.ARS.ABYARA Assembly Area Yes
TACGRP.C2GM.GNL.ARS.EMTARA Engagement Area Yes
TACGRP.C2GM.GNL.ARS.FTFDAR Fortified Area Yes
TACGRP.C2GM.GNL.ARS.DRPZ Drop Zone Yes
TACGRP.C2GM.GNL.ARS.EZ Extraction Zone (EZ) Yes
TACGRP.C2GM.GNL.ARS.LZ Landing Zone (LZ) Yes
TACGRP.C2GM.GNL.ARS.PZ Pickup Zone (PZ) Yes
TACGRP.C2GM.GNL.ARS.SRHARA Search Area/Reconnaissance Area Yes
TACGRP.C2GM.GNL.ARS.LAARA Limited Access Area Yes
TACGRP.C2GM.GNL.ARS.AIRFZ Airfield Zone Yes
TACGRP.C2GM.AVN.PNT.ACP Air Control Point (ACP) Yes
TACGRP.C2GM.AVN.PNT.COMMCP Communications Checkpoint (Ccp) Yes
TACGRP.C2GM.AVN.PNT.PUP Pull-Up Point (PUP) Yes
TACGRP.C2GM.AVN.PNT.DAPP Downed Aircrew Pickup Point Yes
TACGRP.C2GM.AVN.LNE.ACDR Air Corridor Yes
TACGRP.C2GM.AVN.LNE.MRR Minimum Risk Route (MRR) Yes
TACGRP.C2GM.AVN.LNE.SAAFR Standard-Use Army Aircraft Flight Route (SAAFR) Yes
TACGRP.C2GM.AVN.LNE.UAR Unmanned Aircraft (UA) Route Yes
TACGRP.C2GM.AVN.LNE.LLTR Low Level Transit Route (LLTR) Yes
TACGRP.C2GM.AVN.ARS.ROZ Restricted Operations Zone (ROZ) Yes
TACGRP.C2GM.AVN.ARS.SHRDEZ Short-Range Air Defense Engagement Zone (SHORADEZ) Yes
TACGRP.C2GM.AVN.ARS.HIDACZ High Density Airspace Control Zone (HIDACZ) Yes
TACGRP.C2GM.AVN.ARS.MEZ Missile Engagement Zone (MEZ) Yes
TACGRP.C2GM.AVN.ARS.MEZ.LAMEZ Low Altitude Mez Yes
TACGRP.C2GM.AVN.ARS.MEZ.HAMEZ High Altitude Mez Yes
TACGRP.C2GM.AVN.ARS.WFZ Weapons Free Zone Yes
TACGRP.C2GM.DCPN.DMY Dummy (Deception/Decoy) Yes
TACGRP.C2GM.DCPN.AAFF Axis Of Advance For Feint Yes
TACGRP.C2GM.DCPN.DAFF Direction Of Attack For Feint Yes
TACGRP.C2GM.DCPN.DMA Decoy Mined Area
TACGRP.C2GM.DCPN.DMAF Decoy Mined Area, Fenced
TACGRP.C2GM.DCPN.DMYMS Dummy Minefield (Static)
TACGRP.C2GM.DCPN.DMYMD Dummy Minefield (Dynamic)
TACGRP.C2GM.DEF.PNT.TGTREF Target Reference Point (TRP) Yes
TACGRP.C2GM.DEF.PNT.OBSPST Observation Post/Outpost Yes
TACGRP.C2GM.DEF.PNT.OBSPST.CBTPST Combat Outpost Yes
TACGRP.C2GM.DEF.PNT.OBSPST.RECON Observation Post Occupied By Dismounted Scouts Or Reconnaissance Yes
TACGRP.C2GM.DEF.PNT.OBSPST.FWDOP Forward Observer Position Yes
TACGRP.C2GM.DEF.PNT.OBSPST.SOP Sensor Outpost/Listening Post (OP/LP) Yes
TACGRP.C2GM.DEF.PNT.OBSPST.CBRNOP Cbrn Observation Post (Dismounted) Yes
TACGRP.C2GM.DEF.LNE.FEBA Forward Edge Of Battle Area (FEBA) Yes
TACGRP.C2GM.DEF.LNE.PDF Principal Direction Of Fire (PDF) Yes
TACGRP.C2GM.DEF.ARS.BTLPSN Battle Position Yes
TACGRP.C2GM.DEF.ARS.BTLPSN.PBNO Prepared But Not Occupied Yes
TACGRP.C2GM.DEF.ARS.EMTARA Engagement Area Yes
TACGRP.C2GM.OFF.PNT.PNTD Point Of Departure Yes
TACGRP.C2GM.OFF.LNE.AXSADV.AVN Aviation Yes
TACGRP.C2GM.OFF.LNE.AXSADV.ABN Airborne Yes
TACGRP.C2GM.OFF.LNE.AXSADV.ATK Attack, Rotary Wing Yes
TACGRP.C2GM.OFF.LNE.AXSADV.GRD.MANATK Main Attack Yes
TACGRP.C2GM.OFF.LNE.AXSADV.GRD.SUPATK Supporting Attack Yes
TACGRP.C2GM.OFF.LNE.DIRATK.AVN Aviation Yes
TACGRP.C2GM.OFF.LNE.DIRATK.GRD.MANATK Main Attack Yes
TACGRP.C2GM.OFF.LNE.DIRATK.GRD.SUPATK Supporting Attack Yes
TACGRP.C2GM.OFF.LNE.FCL Final Coordination Line Yes
TACGRP.C2GM.OFF.LNE.INFNLE Infiltration Lane Yes
TACGRP.C2GM.OFF.LNE.LMTADV Limit Of Advance Yes
TACGRP.C2GM.OFF.LNE.LD Line Of Departure Yes
TACGRP.C2GM.OFF.LNE.LDLC Line Of Departure/Line Of Contact (LD/LC) Yes
TACGRP.C2GM.OFF.LNE.PLD Probable Line Of Deployment (PLD) Yes
TACGRP.C2GM.OFF.ARS.ASTPSN Assault Position Yes
TACGRP.C2GM.OFF.ARS.ATKPSN Attack Position Yes
TACGRP.C2GM.OFF.ARS.AFP Attack By Fire Position Yes
TACGRP.C2GM.OFF.ARS.SFP Support By Fire Position Yes
TACGRP.C2GM.OFF.ARS.OBJ Objective Yes
TACGRP.C2GM.OFF.ARS.PBX Penetration Box Yes
TACGRP.C2GM.SPL.LNE.AMB Ambush Yes
TACGRP.C2GM.SPL.LNE.HGL Holding Line Yes
TACGRP.C2GM.SPL.LNE.REL Release Line Yes
TACGRP.C2GM.SPL.LNE.BRGH Bridgehead Yes
TACGRP.C2GM.SPL.ARA.AOO Area Of Operations (AO) Yes
TACGRP.C2GM.SPL.ARA.AHD Airhead Yes
TACGRP.C2GM.SPL.ARA.ENCMT Encirclement Yes
TACGRP.C2GM.SPL.ARA.NAI Named Area Of Interest (NAI) Yes
TACGRP.C2GM.SPL.ARA.TAI Targeted Area Of Interest (TAI) Yes
TACGRP.MOBSU.OBST.GNL General
TACGRP.MOBSU.OBST.GNL.BLT Belt
TACGRP.MOBSU.OBST.GNL.LNE Line
TACGRP.MOBSU.OBST.GNL.Z Zone
TACGRP.MOBSU.OBST.GNL.OFA Obstacle Free Area
TACGRP.MOBSU.OBST.GNL.ORA Obstacle Restricted Area
TACGRP.MOBSU.OBST.ABS Abatis
TACGRP.MOBSU.OBST.ATO Antitank Obstacles
TACGRP.MOBSU.OBST.ATO.ATD Antitank Ditch
TACGRP.MOBSU.OBST.ATO.ATD.ATDUC Under Construction
TACGRP.MOBSU.OBST.ATO.ATD.ATDC Antitank Ditch Complete
TACGRP.MOBSU.OBST.ATO.ATDATM Antitank Ditch Reinforced With Antitank Mines
TACGRP.MOBSU.OBST.ATO.TDTSM Antitank Obstacles: Tetrahedrons, Dragons Teeth, And Other Similar Obstacles
TACGRP.MOBSU.OBST.ATO.TDTSM.FIXPFD Fixed And Prefabricated Yes
TACGRP.MOBSU.OBST.ATO.TDTSM.MVB Moveable Yes
TACGRP.MOBSU.OBST.ATO.TDTSM.MVBPFD Moveable And Prefabricated Yes
TACGRP.MOBSU.OBST.ATO.ATW Antitank Wall
TACGRP.MOBSU.OBST.BBY Booby Trap Yes
TACGRP.MOBSU.OBST.MNE.USPMNE Unspecified Mine Yes
TACGRP.MOBSU.OBST.MNE.ATMNE Antitank Mine (At) Yes
TACGRP.MOBSU.OBST.MNE.ATMAHD Antitank Mine With Antihandling Device Yes
TACGRP.MOBSU.OBST.MNE.ATMDIR Antitank Mine (Directional) Yes
TACGRP.MOBSU.OBST.MNE.APMNE Antipersonnel (Ap) Mines Yes
TACGRP.MOBSU.OBST.MNE.WAMNE Wide Area Mines Yes
TACGRP.MOBSU.OBST.MNE.MCLST Mine Cluster
TACGRP.MOBSU.OBST.MNEFLD Minefields
TACGRP.MOBSU.OBST.MNEFLD.STC Static Depiction
TACGRP.MOBSU.OBST.MNEFLD.DYN Dynamic Depiction
TACGRP.MOBSU.OBST.MNEFLD.GAP Gap
TACGRP.MOBSU.OBST.MNEFLD.MNDARA Mined Area
TACGRP.MOBSU.OBST.OBSEFT Obstacle Effect
TACGRP.MOBSU.OBST.OBSEFT.BLK Block
TACGRP.MOBSU.OBST.OBSEFT.FIX Fix
TACGRP.MOBSU.OBST.OBSEFT.TUR Turn
TACGRP.MOBSU.OBST.OBSEFT.DRT Disrupt
TACGRP.MOBSU.OBST.UXO Unexploded Ordnance Area (UXO)
TACGRP.MOBSU.OBST.RCBB Roadblocks, Craters, And Blown Bridges
TACGRP.MOBSU.OBST.RCBB.PLND Planned
TACGRP.MOBSU.OBST.RCBB.SAFE Explosives, State Of Readiness 1 (Safe)
TACGRP.MOBSU.OBST.RCBB.ABP Explosives, State Of Readiness 2 (Armed-But Passable)
TACGRP.MOBSU.OBST.RCBB.EXCD Roadblock (Executed)
TACGRP.MOBSU.OBST.TRIPWR Trip Wire
TACGRP.MOBSU.OBST.WREOBS Wire Obstacle
TACGRP.MOBSU.OBST.WREOBS.USP Unspecified
TACGRP.MOBSU.OBST.WREOBS.SNGFNC Single Fence
TACGRP.MOBSU.OBST.WREOBS.DBLFNC Double Fence
TACGRP.MOBSU.OBST.WREOBS.DAFNC Double Apron Fence
TACGRP.MOBSU.OBST.WREOBS.LWFNC Low Wire Fence
TACGRP.MOBSU.OBST.WREOBS.HWFNC High Wire Fence
TACGRP.MOBSU.OBST.WREOBS.CCTA Concertina
TACGRP.MOBSU.OBST.WREOBS.CCTA.SNG Single Concertina
TACGRP.MOBSU.OBST.WREOBS.CCTA.DBLSTD Double Strand Concertina
TACGRP.MOBSU.OBST.WREOBS.CCTA.TRISTD Triple Strand Concertina
TACGRP.MOBSU.OBST.AVN Aviation
TACGRP.MOBSU.OBST.AVN.TWR.LOW Low Yes
TACGRP.MOBSU.OBST.AVN.TWR.HIGH High Yes
TACGRP.MOBSU.OBST.AVN.OHWIRE Overhead Wire/Power Line
TACGRP.MOBSU.OBSTBP Obstacle Bypass
TACGRP.MOBSU.OBSTBP.DFTY Obstacle Bypass Difficulty
TACGRP.MOBSU.OBSTBP.DFTY.ESY Bypass Easy
TACGRP.MOBSU.OBSTBP.DFTY.DFT Bypass Difficult
TACGRP.MOBSU.OBSTBP.DFTY.IMP Bypass Impossible
TACGRP.MOBSU.OBSTBP.CSGSTE Crossing Site/Water Crossing
TACGRP.MOBSU.OBSTBP.CSGSTE.ASTCA Assault Crossing Area
TACGRP.MOBSU.OBSTBP.CSGSTE.BRG Bridge Or Gap
TACGRP.MOBSU.OBSTBP.CSGSTE.FRY Ferry
TACGRP.MOBSU.OBSTBP.CSGSTE.FRDESY Ford Easy
TACGRP.MOBSU.OBSTBP.CSGSTE.FRDDFT Ford Difficult
TACGRP.MOBSU.OBSTBP.CSGSTE.LANE Lane
TACGRP.MOBSU.OBSTBP.CSGSTE.RFT Raft Site
TACGRP.MOBSU.OBSTBP.CSGSTE.ERP Engineer Regulating Point Yes
TACGRP.MOBSU.SU Survivability
TACGRP.MOBSU.SU.ESTOF Earthwork, Small Trench Or Fortification Yes
TACGRP.MOBSU.SU.FRT Fort Yes
TACGRP.MOBSU.SU.FTFDLN Fortified Line
TACGRP.MOBSU.SU.FEWS Foxhole, Emplacement Or Weapon Site
TACGRP.MOBSU.SU.STRGPT Strong Point
TACGRP.MOBSU.SU.SUFSHL Surface Shelter Yes
TACGRP.MOBSU.SU.UGDSHL Underground Shelter Yes
TACGRP.MOBSU.CBRN.MSDZ Minimum Safe Distance Zones Yes
TACGRP.MOBSU.CBRN.NDGZ Nuclear Detonations Ground Zero Yes
TACGRP.MOBSU.CBRN.FAOTP Fallout Producing Yes
TACGRP.MOBSU.CBRN.RADA Radioactive Area Yes
TACGRP.MOBSU.CBRN.BIOCA Biologically Contaminated Area Yes
TACGRP.MOBSU.CBRN.CMLCA Chemically Contaminated Area Yes
TACGRP.MOBSU.CBRN.REEVNT.BIO Biological Yes
TACGRP.MOBSU.CBRN.REEVNT.CML Chemical Yes
TACGRP.MOBSU.CBRN.DECONP Decontamination (Decon) Points Yes
TACGRP.MOBSU.CBRN.DECONP.USP Decon Site/Point (Unspecified) Yes
TACGRP.MOBSU.CBRN.DECONP.ALTUSP Alternate Decon Site/Point (Unspecified) Yes
TACGRP.MOBSU.CBRN.DECONP.TRP Decon Site/Point (Troops) Yes
TACGRP.MOBSU.CBRN.DECONP.EQT Decon Site/Point (Equipment) Yes
TACGRP.MOBSU.CBRN.DECONP.EQTTRP Decon Site/Point (Equipment And Troops) Yes
TACGRP.MOBSU.CBRN.DECONP.OPDECN Decon Site/Point (Operational Decontamination) Yes
TACGRP.MOBSU.CBRN.DECONP.TRGH Decon Site/Point (Thorough Decontamination) Yes
TACGRP.MOBSU.CBRN.DRCL Dose Rate Contour Lines Yes
TACGRP.FSUPP.PNT.TGT.PTGT Point/Single Target Yes
TACGRP.FSUPP.PNT.TGT.NUCTGT Nuclear Target Yes
TACGRP.FSUPP.PNT.C2PNT Command & Control Points Yes
TACGRP.FSUPP.PNT.C2PNT.FSS Fire Support Station Yes
TACGRP.FSUPP.PNT.C2PNT.SCP Survey Control Point Yes
TACGRP.FSUPP.PNT.C2PNT.FP Firing Point Yes
TACGRP.FSUPP.PNT.C2PNT.RP Reload Point Yes
TACGRP.FSUPP.PNT.C2PNT.HP Hide Point Yes
TACGRP.FSUPP.PNT.C2PNT.LP Launch Point Yes
TACGRP.FSUPP.LNE.LNRTGT Linear Target Yes
TACGRP.FSUPP.LNE.LNRTGT.LSTGT Linear Smoke Target Yes
TACGRP.FSUPP.LNE.LNRTGT.FPF Final Protective Fire (FPF) Yes
TACGRP.FSUPP.LNE.C2LNE.FSCL Fire Support Coordination Line (FSCL) Yes
TACGRP.FSUPP.LNE.C2LNE.CFL Coordinated Fire Line (CFL) Yes
TACGRP.FSUPP.LNE.C2LNE.NFL No-Fire Line (NFL) Yes
TACGRP.FSUPP.LNE.C2LNE.RFL Restrictive Fire Line (RFL) Yes
TACGRP.FSUPP.LNE.C2LNE.MFP Munition Flight Path (MFP) Yes
TACGRP.FSUPP.ARS.ARATGT Area Target Yes
TACGRP.FSUPP.ARS.ARATGT.RTGTGT Rectangular Target Yes
TACGRP.FSUPP.ARS.ARATGT.CIRTGT Circular Target Yes
TACGRP.FSUPP.ARS.ARATGT.SGTGT Series Or Group Of Targets Yes
TACGRP.FSUPP.ARS.ARATGT.SMK Smoke Yes
TACGRP.FSUPP.ARS.ARATGT.BMARA Bomb Area Yes
TACGRP.FSUPP.ARS.C2ARS.FSA.IRR Fire Support Area (FSA), Irregular Yes
TACGRP.FSUPP.ARS.C2ARS.FSA.RTG Fire Support Area (FSA), Rectangular Yes
TACGRP.FSUPP.ARS.C2ARS.FSA.CIRCLR Fire Support Area (FSA), Circular Yes
TACGRP.FSUPP.ARS.C2ARS.ACA.IRR Airspace Coordination Area (ACA), Irregular Yes
TACGRP.FSUPP.ARS.C2ARS.ACA.RTG Airspace Coordination Area (ACA), Rectangular Yes
TACGRP.FSUPP.ARS.C2ARS.ACA.CIRCLR Airspace Coordination Area (ACA), Circular Yes
TACGRP.FSUPP.ARS.C2ARS.FFA.IRR Free Fire Area (FFA), Irregular Yes
TACGRP.FSUPP.ARS.C2ARS.FFA.RTG Free Fire Area (FFA), Rectangular Yes
TACGRP.FSUPP.ARS.C2ARS.FFA.CIRCLR Free Fire Area (FFA), Circular Yes
TACGRP.FSUPP.ARS.C2ARS.NFA.IRR No Fire Area (NFA), Irregular Yes
TACGRP.FSUPP.ARS.C2ARS.NFA.RTG No Fire Area (NFA), Rectangular Yes
TACGRP.FSUPP.ARS.C2ARS.NFA.CIRCLR No Fire Area (NFA), Circular Yes
TACGRP.FSUPP.ARS.C2ARS.RFA.IRR Restrictive Fire Area (RFA), Irregular Yes
TACGRP.FSUPP.ARS.C2ARS.RFA.RTG Restrictive Fire Area (RFA), Rectangular Yes
TACGRP.FSUPP.ARS.C2ARS.RFA.CIRCLR Restrictive Fire Area (RFA), Circular Yes
TACGRP.FSUPP.ARS.C2ARS.PAA.RTG Position Area For Artillery (PAA), Rectangular Yes
TACGRP.FSUPP.ARS.C2ARS.PAA.CIRCLR Position Area For Artillery (PAA), Circular Yes
TACGRP.FSUPP.ARS.C2ARS.SNSZ.IRR Sensor Zone, Irregular Yes
TACGRP.FSUPP.ARS.C2ARS.SNSZ.RTG Sensor Zone, Rectangular Yes
TACGRP.FSUPP.ARS.C2ARS.SNSZ.CIRCLR Sensor Zone , Circular Yes
TACGRP.FSUPP.ARS.C2ARS.DA.IRR Dead Space Area (DA), Irregular Yes
TACGRP.FSUPP.ARS.C2ARS.DA.RTG Dead Space Area (DA), Rectangular Yes
TACGRP.FSUPP.ARS.C2ARS.DA.CIRCLR Dead Space Area (DA), Circular Yes
TACGRP.FSUPP.ARS.C2ARS.ZOR.IRR Zone Of Responsibility (ZOR), Irregular Yes
TACGRP.FSUPP.ARS.C2ARS.ZOR.RTG Zone Of Responsibility (ZOR), Rectangular Yes
TACGRP.FSUPP.ARS.C2ARS.ZOR.CIRCLR Zone Of Responsibility (ZOR), Circular Yes
TACGRP.FSUPP.ARS.C2ARS.TBA.IRR Target Build Up Area (TBA), Irregular Yes
TACGRP.FSUPP.ARS.C2ARS.TBA.RTG Target Build Up Area (TBA), Rectangular Yes
TACGRP.FSUPP.ARS.C2ARS.TBA.CIRCLR Target Build Up Area (TBA), Circular Yes
TACGRP.FSUPP.ARS.C2ARS.TVAR.IRR Target Value Area (TVAR), Irregular Yes
TACGRP.FSUPP.ARS.C2ARS.TVAR.RTG Target Value Area (TVAR), Rectangular Yes
TACGRP.FSUPP.ARS.C2ARS.TVAR.CIRCLR Target Value Area (TVAR), Circular Yes
TACGRP.FSUPP.ARS.C2ARS.TGMF Terminally Guided Munition Footprint (TGMF) Yes
TACGRP.FSUPP.ARS.TGTAQZ.ATIZ.IRR Artillery Target Intelligence (ATI) Zone, Irregular Yes
TACGRP.FSUPP.ARS.TGTAQZ.ATIZ.RTG Artillery Target Intelligence (ATI) Zone, Rectangular Yes
TACGRP.FSUPP.ARS.TGTAQZ.CFFZ.IRR Call For Fire Zone (CFFZ), Irregular Yes
TACGRP.FSUPP.ARS.TGTAQZ.CFFZ.RTG Call For Fire Zone (CFFZ), Rectangular Yes
TACGRP.FSUPP.ARS.TGTAQZ.CNS.IRR Censor Zone, Irregular Yes
TACGRP.FSUPP.ARS.TGTAQZ.CNS.RTG Censor Zone, Rectangular Yes
TACGRP.FSUPP.ARS.TGTAQZ.CFZ.IRR Critical Friendly Zone (CFZ), Irregular Yes
TACGRP.FSUPP.ARS.TGTAQZ.CFZ.RTG Critical Friendly Zone (CFZ), Rectangular Yes
TACGRP.FSUPP.ARS.WPNRF.CIRCLR Weapon/Sensor Range Fan, Circular Yes
TACGRP.FSUPP.ARS.WPNRF.SCR Weapon/Sensor Range Fan, Sector Yes
TACGRP.FSUPP.ARS.KLBOX.BLUE.CIRCLR Blue Kill Box, Circular Yes
TACGRP.FSUPP.ARS.KLBOX.BLUE.IRR Blue Kill Box, Irregular Yes
TACGRP.FSUPP.ARS.KLBOX.BLUE.RTG Blue Kill Box, Rectangular Yes
TACGRP.FSUPP.ARS.KLBOX.PURPLE.CIRCLR Purple Kill Box, Circular Yes
TACGRP.FSUPP.ARS.KLBOX.PURPLE.IRR Purple Kill Box, Irregular Yes
TACGRP.FSUPP.ARS.KLBOX.PURPLE.RTG Purple Kill Box, Rectangular Yes
TACGRP.CSS.PNT.AEP Ambulance Exchange Point Yes
TACGRP.CSS.PNT.CBNP Cannibalization Point Yes
TACGRP.CSS.PNT.CCP Casualty Collection Point Yes
TACGRP.CSS.PNT.CVP Civilian Collection Point Yes
TACGRP.CSS.PNT.DCP Detainee Collection Point Yes
TACGRP.CSS.PNT.EPWCP Enemy Prisoner Of War (EPW) Collection Point Yes
TACGRP.CSS.PNT.LRP Logistics Release Point (LRP) Yes
TACGRP.CSS.PNT.MCP Maintenance Collection Point Yes
TACGRP.CSS.PNT.RRRP Rearm, Refuel And Resupply Point Yes
TACGRP.CSS.PNT.ROM Refuel On The Move (ROM) Point Yes
TACGRP.CSS.PNT.TCP Traffic Control Post (TCP) Yes
TACGRP.CSS.PNT.TTP Trailer Transfer Point Yes
TACGRP.CSS.PNT.UMC Unit Maintenance Collection Point Yes
TACGRP.CSS.PNT.SPT Supply Points Yes
TACGRP.CSS.PNT.SPT.GNL General Yes
TACGRP.CSS.PNT.SPT.CLS1 Class I Yes
TACGRP.CSS.PNT.SPT.CLS2 Class II Yes
TACGRP.CSS.PNT.SPT.CLS3 Class III Yes
TACGRP.CSS.PNT.SPT.CLS4 Class IV Yes
TACGRP.CSS.PNT.SPT.CLS5 Class V Yes
TACGRP.CSS.PNT.SPT.CLS6 Class VI Yes
TACGRP.CSS.PNT.SPT.CLS7 Class VII Yes
TACGRP.CSS.PNT.SPT.CLS8 Class VIII Yes
TACGRP.CSS.PNT.SPT.CLS9 Class IX Yes
TACGRP.CSS.PNT.SPT.CLS10 Class X Yes
TACGRP.CSS.PNT.AP Ammunition Points Yes
TACGRP.CSS.PNT.AP.ASP Ammunition Supply Point (ASP) Yes
TACGRP.CSS.PNT.AP.ATP Ammunition Transfer Point (ATP) Yes
TACGRP.CSS.LNE.CNY Convoys
TACGRP.CSS.LNE.CNY.MCNY Moving Convoy
TACGRP.CSS.LNE.CNY.HCNY Halted Convoy
TACGRP.CSS.LNE.SLPRUT Supply Routes
TACGRP.CSS.LNE.SLPRUT.MSRUT Main Supply Route
TACGRP.CSS.LNE.SLPRUT.ASRUT Alternate Supply Route
TACGRP.CSS.LNE.SLPRUT.1WTRFF One-Way Traffic
TACGRP.CSS.LNE.SLPRUT.ATRFF Alternating Traffic
TACGRP.CSS.LNE.SLPRUT.2WTRFF Two-Way Traffic
TACGRP.CSS.ARA.DHA Detainee Holding Area Yes
TACGRP.CSS.ARA.EPWHA Enemy Prisoner Of War (Epw) Holding Area Yes
TACGRP.CSS.ARA.FARP Forward Arming And Refueling Area (FARP) Yes
TACGRP.CSS.ARA.RHA Refugee Holding Area Yes
TACGRP.CSS.ARA.SUPARS Support Areas
TACGRP.CSS.ARA.SUPARS.BSA Brigade (BSA) Yes
TACGRP.CSS.ARA.SUPARS.DSA Division (DSA) Yes
TACGRP.CSS.ARA.SUPARS.RSA Regimental (Rsa) Yes
TACGRP.OTH.ER.DTHAC Ditched Aircraft Yes
TACGRP.OTH.ER.PIW Person In Water Yes
TACGRP.OTH.ER.DSTVES Distressed Vessel Yes
TACGRP.OTH.HAZ.SML Sea Mine-Like Yes
TACGRP.OTH.HAZ.NVGL Navigational
TACGRP.OTH.HAZ.IB Iceberg Yes
TACGRP.OTH.HAZ.OLRG Oil Rig Yes
TACGRP.OTH.SSUBSR.BTMRTN Bottom Return/Non-Milco Yes
TACGRP.OTH.SSUBSR.BTMRTN.INS Installation/Manmade Yes
TACGRP.OTH.SSUBSR.BTMRTN.SBRSOO Seabed Rock/Stone, Obstacle, Other Yes
TACGRP.OTH.SSUBSR.BTMRTN.WRKND Wreck, Non Dangerous Yes
TACGRP.OTH.SSUBSR.BTMRTN.WRKD Wreck, Dangerous Yes
TACGRP.OTH.SSUBSR.MARLFE Marine Life Yes
TACGRP.OTH.SSUBSR.SA Sea Anomaly (Wake, Current, Knuckle) Yes
TACGRP.OTH.BERLNE Bearing Line
TACGRP.OTH.BERLNE.ELC Electronic
TACGRP.OTH.BERLNE.ACU Acoustic
TACGRP.OTH.BERLNE.TPD Torpedo
TACGRP.OTH.BERLNE.EOPI Electro-Optical Intercept
TACGRP.OTH.FIX Fix
TACGRP.OTH.FIX.ACU Acoustic Yes
TACGRP.OTH.FIX.EM Electro-Magnetic Yes
TACGRP.OTH.FIX.EOP Electro-Optical Yes



Appendix C, Meteorological and Oceanographic

Hierarchy Description Supported
AMPHC.PRS.LOWCTR Low pressure center Yes
AMPHC.PRS.LOWCTR.CYC Cyclone center Yes
AMPHC.PRS.LOWCTR.TROPLW Tropopause low Yes
AMPHC.PRS.HGHCTR High pressure center Yes
AMPHC.PRS.HGHCTR.ACYC Anticyclone center Yes
AMPHC.PRS.HGHCTR.TROPHG Tropopause high Yes
AMPHC.PRS.FRNSYS Frontal systems
AMPHC.PRS.FRNSYS.CLDFRN Cold front
AMPHC.PRS.FRNSYS.CLDFRN.UPP Upper cold front
AMPHC.PRS.FRNSYS.CLDFRN.FRGS Cold frontogenesis
AMPHC.PRS.FRNSYS.CLDFRN.FRLS Cold frontolysis
AMPHC.PRS.FRNSYS.WRMFRN Warm front
AMPHC.PRS.FRNSYS.WRMFRN.UPP Upper warm front
AMPHC.PRS.FRNSYS.WRMFRN.FRGS Warm frontogenesis
AMPHC.PRS.FRNSYS.WRMFRN.FRLS Warm frontolysis
AMPHC.PRS.FRNSYS.OCD Occluded front
AMPHC.PRS.FRNSYS.OCD.UPP Upper occluded front
AMPHC.PRS.FRNSYS.OCD.FRLS Occluded frontolysis
AMPHC.PRS.FRNSYS.STAT Stationary front
AMPHC.PRS.FRNSYS.STAT.UPP Upper stationary front
AMPHC.PRS.FRNSYS.STAT.FRGS Stationary frontogenesis
AMPHC.PRS.FRNSYS.STAT.FRLS Stationary frontolysis
AMPHC.PRS.LNE.TRUAXS Pressure systems, trough axis
AMPHC.PRS.LNE.RDGAXS Ridge axis
AMPHC.PRS.LNE.SSL Severe squall line
AMPHC.PRS.LNE.ISTB Instability line
AMPHC.PRS.LNE.SHA Shear line
AMPHC.PRS.LNE.ITCZ Inter-tropical convergance zone
AMPHC.PRS.LNE.CNGLNE Convergance line
AMPHC.PRS.LNE.ITD Inter-tropical discontinuity
AMPHC.TRB.LIT Turbulence – light Yes
AMPHC.TRB.MOD Turbulence – moderate Yes
AMPHC.TRB.SVR Turbulence – severe Yes
AMPHC.TRB.EXT Turbulence – extreme Yes
AMPHC.TRB.MNTWAV Mountain waves Yes
AMPHC.ICG.CLR.LIT Clear icing – light Yes
AMPHC.ICG.CLR.MOD Clear icing – moderate Yes
AMPHC.ICG.CLR.SVR Clear icing – severe Yes
AMPHC.ICG.RIME.LIT Rime icing – light Yes
AMPHC.ICG.RIME.MOD Rime icing – moderate Yes
AMPHC.ICG.RIME.SVR Rime icing – severe Yes
AMPHC.ICG.MIX.LIT Mixed icing – light Yes
AMPHC.ICG.MIX.MOD Mixed icing – moderate Yes
AMPHC.ICG.MIX.SVR Mixed icing – severe Yes
AMPHC.WND.CALM Calm winds Yes
AMPHC.WND.PLT Wind plot
AMPHC.WND.JTSM Jet stream
AMPHC.WND.SMLNE Stream line
AMPHC.CUDCOV.SYM.SKC Clear sky Yes
AMPHC.CUDCOV.SYM.FEW Few coverage Yes
AMPHC.CUDCOV.SYM.SCT Scattered coverage Yes
AMPHC.CUDCOV.SYM.BKN Broken coverage Yes
AMPHC.CUDCOV.SYM.OVC Overcast coverage Yes
AMPHC.CUDCOV.SYM.STOPO Sky totally or partially obscured Yes
AMPHC.WTH.RA.INMLIT Rain – intermittent light Yes
AMPHC.WTH.RA.INMLIT.CTSLIT Rain – continuous light Yes
AMPHC.WTH.RA.INMMOD Rain – intermittent moderate Yes
AMPHC.WTH.RA.INMMOD.CTSMOD Rain – continuous moderate Yes
AMPHC.WTH.RA.INMHVY Rain – intermittent heavy Yes
AMPHC.WTH.RA.INMHVY.CTSHVY Rain – continuous heavy Yes
AMPHC.WTH.FZRA.LIT Freezing rain – light Yes
AMPHC.WTH.FZRA.MODHVY Freezing rain – moderate/heavy Yes
AMPHC.WTH.RASWR.LIT Rain showers – light Yes
AMPHC.WTH.RASWR.MODHVY Rain showers – moderate/heavy Yes
AMPHC.WTH.RASWR.TOR Rain showers – torrential Yes
AMPHC.WTH.DZ.INMLIT Drizzle – intermittent light Yes
AMPHC.WTH.DZ.INMLIT.CTSLIT Drizzle – continuous light Yes
AMPHC.WTH.DZ.INMMOD Drizzle – intermittent moderate Yes
AMPHC.WTH.DZ.INMMOD.CTSMOD Drizzle – continuous moderate Yes
AMPHC.WTH.DZ.INMHVY Drizzle – intermittent heavy Yes
AMPHC.WTH.DZ.INMHVY.CTSHVY Drizzle – continuous heavy Yes
AMPHC.WTH.FZDZ.LIT Freezing drizzle – light Yes
AMPHC.WTH.FZDZ.MODHVY Freezing drizzle – moderate/heavy Yes
AMPHC.WTH.RASN.RDSLIT Rain or drizzle and snow – light Yes
AMPHC.WTH.RASN.RDSMH Rain or drizzle and snow – moderate/heavy Yes
AMPHC.WTH.RASN.SWRLIT Rain and snow showers – light Yes
AMPHC.WTH.RASN.SWRMOD Rain and snow showers – moderate/heavy Yes
AMPHC.WTH.SN.INMLIT Snow – intermittent light Yes
AMPHC.WTH.SN.INMLIT.CTSLIT Snow – continuous light Yes
AMPHC.WTH.SN.INMMOD Snow – intermittent moderate Yes
AMPHC.WTH.SN.INMMOD.CTSMOD Snow – continuous moderate Yes
AMPHC.WTH.SN.INMHVY Snow – intermittent heavy Yes
AMPHC.WTH.SN.INMHVY.CTSHVY Snow – continuous heavy Yes
AMPHC.WTH.SN.BLSNLM Blowing snow – light/moderate Yes
AMPHC.WTH.SN.BLSNHY Blowing snow – heavy Yes
AMPHC.WTH.SG Snow grains Yes
AMPHC.WTH.SSWR.LIT Snow showers – light Yes
AMPHC.WTH.SSWR.MODHVY Snow showers – moderate/heavy Yes
AMPHC.WTH.HL.LIT Hail – light not associated with thunder Yes
AMPHC.WTH.HL.MODHVY Hail – moderate/heavy not associated with thunder Yes
AMPHC.WTH.IC Ice crystals (diamond dust) Yes
AMPHC.WTH.PE.LIT Ice pellets – light Yes
AMPHC.WTH.PE.MOD Ice pellets – moderate Yes
AMPHC.WTH.PE.HVY Ice pellets – heavy Yes
AMPHC.WTH.STMS.TS Thunderstorm – no precipitation Yes
AMPHC.WTH.STMS.TSLMNH Thunderstorm light to moderate with rain/snow – no hail Yes
AMPHC.WTH.STMS.TSHVNH Thunderstorm heavy with rain/snow – no hail Yes
AMPHC.WTH.STMS.TSLMWH Thunderstorm light to moderate – with hail Yes
AMPHC.WTH.STMS.TSHVWH Thunderstorm heavy – with hail Yes
AMPHC.WTH.STMS.FC Funnel cloud (tornado/waterspout) Yes
AMPHC.WTH.STMS.SQL Squall Yes
AMPHC.WTH.STMS.LTG Lightning Yes
AMPHC.WTH.FG.SHWPTH Fog – shallow patches Yes
AMPHC.WTH.FG.SHWCTS Fog \-shallow continuous Yes
AMPHC.WTH.FG.PTHY Fog – patchy Yes
AMPHC.WTH.FG.SKYVSB Fog – sky visible Yes
AMPHC.WTH.FG.SKYOBD Fog – sky obscured Yes
AMPHC.WTH.FG.FZSV Fog – freezing, sky visible Yes
AMPHC.WTH.FG.FZSNV Fog – freezing, sky not visible Yes
AMPHC.WTH.MIST Mist Yes
AMPHC.WTH.FU Smoke Yes
AMPHC.WTH.HZ Haze Yes
AMPHC.WTH.DTSD.LITMOD Dust/sand storm – light to moderate Yes
AMPHC.WTH.DTSD.SVR Dust/sand storm – severe Yes
AMPHC.WTH.DTSD.DTDVL Dust devil Yes
AMPHC.WTH.DTSD.BLDTSD Blowing dust or sand
AMPHC.WTH.TPLSYS.TROPDN Tropical depression Yes
AMPHC.WTH.TPLSYS.TROPSM Tropical storm Yes
AMPHC.WTH.TPLSYS.HC Hurricane/typhoon Yes
AMPHC.WTH.TPLSYS.TSWADL Tropical storm wind areas and date/time labels
AMPHC.WTH.VOLERN Volcanic eruption Yes
AMPHC.WTH.VOLERN.VOLASH Volcanic ash Yes
AMPHC.WTH.TROPLV Tropopause level Yes
AMPHC.WTH.FZLVL Freezing level Yes
AMPHC.WTH.POUTAI Precipitation of unknown type and intensity Yes
AMPHC.BDAWTH.IFR Instrument flight rule (IFR)
AMPHC.BDAWTH.MVFR Marginal visual flight rule (MVFR)
AMPHC.BDAWTH.TRB Turbulence
AMPHC.BDAWTH.ICG Icing
AMPHC.BDAWTH.LPNCI Liquid precipitation – non-convective
AMPHC.BDAWTH.LPNCI.LPC Liquid precipitation – convective
AMPHC.BDAWTH.FZPPN Freezing/frozen precipitation
AMPHC.BDAWTH.TS Thunderstorms
AMPHC.BDAWTH.FG Fog
AMPHC.BDAWTH.DTSD Dust or sand
AMPHC.BDAWTH.ODFF Operator-defined freeform
AMPHC.ISP.ISB Isobar – surface
AMPHC.ISP.CTUR Contour – upper air
AMPHC.ISP.IST Isotherm
AMPHC.ISP.ISH Isotach
AMPHC.ISP.ISD Isodrosotherm
AMPHC.ISP.THK Thickness
AMPHC.ISP.ODFF Operator-defined freeform
AMPHC_STOG_WOSMIC_SUFDRY Surface dry
AMPHC.STOG.WOSMIC.SUFMST Surface moist
AMPHC.STOG.WOSMIC.SUFWET Surface wet
AMPHC.STOG.WOSMIC.SUFFLD Surface flooded
AMPHC.STOG.WOSMIC.SUFFZN Surface frozen
AMPHC.STOG.WOSMIC.GLZGRD Glaze (thin ice) on ground Yes
AMPHC.STOG.WOSMIC.LDNCGC Loose dry dust or sand not covering ground completely
AMPHC.STOG.WOSMIC.TLDCGC Thin loose dry dust or sand covering ground completely
AMPHC.STOG.WOSMIC.MLDCGC Moderate/thick loose dry dust or sand covering ground completely
AMPHC.STOG.WOSMIC.EXTDWC Extremely dry with cracks Yes
AMPHC.STOG.WSMIC.PDMIC Predominately ice covered Yes
AMPHC.STOG.WSMIC.CWSNLH Compact or wet snow (with or without ice)
AMPHC.STOG.WSMIC.CSNALH Compact or wet snow (with or without ice)
AMPHC.STOG.WSMIC.ELCSCG Even layer of compact or wet snow covering
AMPHC.STOG.WSMIC.ULCSCG Uneven layer of compact or wet snow
AMPHC.STOG.WSMIC.LDSNLH Loose dry snow covering less than one-half
AMPHC.STOG.WSMIC.LDSALH Loose dry snow covering at least one-half
AMPHC.STOG.WSMIC.ELDSCG Even layer of loose dry snow covering
AMPHC.STOG.WSMIC.ULDSCG Uneven layer of loose dry snow covering
AMPHC.STOG.WSMIC.SCGC Snow covering ground Yesly Yes
OCA.ISYS.IB Icebergs Yes
OCA.ISYS.IB.MNY Many icebergs Yes
OCA.ISYS.IB.BAS Belts and strips Yes
OCA.ISYS.IB.GNL Iceberg \-general Yes
OCA.ISYS.IB.MNYGNL Many icebergs \-general Yes
OCA.ISYS.IB.BB Bergy bit Yes
OCA.ISYS.IB.MNYBB Many bergy bits Yes
OCA.ISYS.IB.GWL Growler Yes
OCA.ISYS.IB.MNYGWL Many growlers Yes
OCA.ISYS.IB.FBG Floeberg Yes
OCA.ISYS.IB.II Ice island Yes
OCA.ISYS.ICN.BW Bergy water Yes
OCA.ISYS.ICN.WWRT Water with radar targets Yes
OCA.ISYS.ICN.IF Ice free Yes
OCA.ISYS.DYNPRO.CNG Convergence Yes
OCA.ISYS.DYNPRO.DVG Divergence Yes
OCA.ISYS.DYNPRO.SHAZ Shearing or shear zone Yes
OCA.ISYS.DYNPRO.ID Ice drift (direction)
OCA.ISYS.SI Sea ice Yes
OCA.ISYS.SI.ITOBS Ice thickness (observed)
OCA.ISYS.SI.ITEST Ice thickness (estimated)
OCA.ISYS.SI.MPOFI Melt puddles or flooded ice Yes
OCA.ISYS.LMT.LOVO Limit of visual observation
OCA.ISYS.LMT.LOU Limit of undercast
OCA.ISYS.LMT.LORO Limit of radar observation
OCA.ISYS.LMT.OIEOB Observed ice edge or boundary
OCA.ISYS.LMT.EIEOB Estimated ice edge or boundary
OCA.ISYS.LMT.IEOBFR Ice edge or boundary from radar
OCA.ISYS.OITI.CRK Openings in the ice, cracks
OCA.ISYS.OITI.CRKASL Cracks at a specific location
OCA.ISYS.OITI.LED Lead
OCA.ISYS.OITI.FZLED Frozen lead
OCA.ISYS.SC Snow cover Yes
OCA.ISYS.SC.SWO Sastrugi (with orientation) Yes
OCA.ISYS.TOPFTR.HUM Ridges or hummocks Yes
OCA.ISYS.TOPFTR.RFTG Rafting Yes
OCA.ISYS.TOPFTR.JBB Jammed brash barrier Yes
OCA.HYDGRY.DPH.SNDG Soundings Yes
OCA.HYDGRY.DPH.CRV Depth curve
OCA.HYDGRY.DPH.CTUR Depth contour
OCA.HYDGRY.DPH.ARA Depth area
OCA.HYDGRY.CSTHYD.CSTLN Coastline
OCA.HYDGRY.CSTHYD.ISND Island
OCA.HYDGRY.CSTHYD.BEH Beach
OCA.HYDGRY.CSTHYD.H2O Water
OCA.HYDGRY.CSTHYD.FSH1.FSH2 Foreshore
OCA.HYDGRY.CSTHYD.FSH1.FSH3 Foreshore
OCA.HYDGRY.PRTHBR.PRT.BRHSO Berths (onshore) Yes
OCA.HYDGRY.PRTHBR.PRT.BRHSA Berths (anchor) Yes
OCA.HYDGRY.PRTHBR.PRT.ANCRG1 Anchorage Yes
OCA.HYDGRY.PRTHBR.PRT.ANCRG2 Anchorage
OCA.HYDGRY.PRTHBR.PRT.ANCRG3 Anchorage
OCA.HYDGRY.PRTHBR.PRT.CIP Call in point Yes
OCA.HYDGRY.PRTHBR.PRT.PWQ Pier/wharf/quay
OCA.HYDGRY.PRTHBR.FSG.FSGHBR Fishing harbor Yes
OCA.HYDGRY.PRTHBR.FSG.FSTK1 Fish stakes/traps/weirs Yes
OCA.HYDGRY.PRTHBR.FSG.FSTK2 Fish stakes/traps/weirs
OCA.HYDGRY.PRTHBR.FSG.FSTK3 Fish stakes/traps/weirs
OCA.HYDGRY.PRTHBR.FAC.DDCK Drydock
OCA.HYDGRY.PRTHBR.FAC.LNDPLC Landing place Yes
OCA.HYDGRY.PRTHBR.FAC.OSLF1 Offshore loading facility Yes
OCA.HYDGRY.PRTHBR.FAC.OSLF2 Offshore loading facility
OCA.HYDGRY.PRTHBR.FAC.OSLF3 Offshore loading facility
OCA.HYDGRY.PRTHBR.FAC.RAMPAW Ramp (above water)
OCA.HYDGRY.PRTHBR.FAC.RAMPBW Ramp (below water)
OCA.HYDGRY.PRTHBR.FAC.LNDRNG Landing ring Yes
OCA.HYDGRY.PRTHBR.FAC.FRYCSG Ferry crossing
OCA.HYDGRY.PRTHBR.FAC.CFCSG Cable ferry crossing
OCA.HYDGRY.PRTHBR.FAC.DOPN Dolphin Yes
OCA.HYDGRY.PRTHBR.SHRLNE.BWGJAW Breakwater/groin/jetty
OCA.HYDGRY.PRTHBR.SHRLNE.BWGJBW Breakwater/groin/jetty
OCA.HYDGRY.PRTHBR.SHRLNE.SW Seawall
OCA.HYDGRY.ATN.BCN Beacon Yes
OCA.HYDGRY.ATN.BUOY Buoy default Yes
OCA.HYDGRY.ATN.MRK Marker Yes
OCA.HYDGRY.ATN.PRH1.PRH2 Perches/stakes Yes
OCA.HYDGRY.ATN.PRH1.PRH3 Perches/stakes
OCA.HYDGRY.ATN.LIT Light Yes
OCA.HYDGRY.ATN.LDGLNE Leading line
OCA.HYDGRY.ATN.LITVES Light vessel/lightship Yes
OCA.HYDGRY.ATN.LITHSE Lighthouse Yes
OCA.HYDGRY.DANHAZ.RCKSBM Rock submergered Yes
OCA.HYDGRY.DANHAZ.RCKAWD Rock awashed Yes
OCA.HYDGRY.DANHAZ.UH2DAN Underwater danger/hazard
OCA.HYDGRY.DANHAZ.FLGRD1.FLGRD2 Foul ground Yes
OCA.HYDGRY.DANHAZ.FLGRD1.FLGRD3 Foul ground
OCA.HYDGRY.DANHAZ.KLP1.KLP2 Kelp/seaweed Yes
OCA.HYDGRY.DANHAZ.KLP1.KLP3 Kelp/seaweed
OCA.HYDGRY.DANHAZ.MNENAV.DBT Mine – naval (doubtful) Yes
OCA.HYDGRY.DANHAZ.MNENAV.DEFN Mine – naval (definite) Yes
OCA.HYDGRY.DANHAZ.SNAG Snags/stumps Yes
OCA.HYDGRY.DANHAZ.WRK.UCOV Wreck (uncovers) Yes
OCA.HYDGRY.DANHAZ.WRK.SBM Wreck (submerged) Yes
OCA.HYDGRY.DANHAZ.BRKS Breakers
OCA.HYDGRY.DANHAZ.REEF Reef
OCA.HYDGRY.DANHAZ.EOTR Eddies/overfalls/tide rips Yes
OCA.HYDGRY.DANHAZ.DCDH2O Discolored water
OCA.HYDGRY.BTMFAT.BTMCHR.SD Sand Yes
OCA.HYDGRY.BTMFAT.BTMCHR.MUD Mud Yes
OCA.HYDGRY.BTMFAT.BTMCHR.CLAY Clay Yes
OCA.HYDGRY.BTMFAT.BTMCHR.SLT Silt Yes
OCA.HYDGRY.BTMFAT.BTMCHR.STNE Stones Yes
OCA.HYDGRY.BTMFAT.BTMCHR.GVL Gravel Yes
OCA.HYDGRY.BTMFAT.BTMCHR.PBL Pebbles Yes
OCA.HYDGRY.BTMFAT.BTMCHR.COBL Cobbles Yes
OCA.HYDGRY.BTMFAT.BTMCHR.RCK Rock Yes
OCA.HYDGRY.BTMFAT.BTMCHR.CRL Coral Yes
OCA.HYDGRY.BTMFAT.BTMCHR.SHE Shell Yes
OCA.HYDGRY.BTMFAT.QLFYTM.FNE Qualifying terms, fine Yes
OCA.HYDGRY.BTMFAT.QLFYTM.MDM Qualifying terms, medum Yes
OCA.HYDGRY.BTMFAT.QLFYTM.CSE Qualifying terms, coarse Yes
OCA.HYDGRY.TDECUR.H2OTRB Water turbulence Yes
OCA.HYDGRY.TDECUR.EBB Current flow – ebb
OCA.HYDGRY.TDECUR.FLOOD Current flow – flood
OCA.HYDGRY.TDECUR.TDEDP Tide data point Yes
OCA.HYDGRY.TDECUR.TDEG Tide gauge Yes
OCA.OCNGRY.BIOLUM.VDR1.2 Bioluminescence, vdr level 1-2
OCA.OCNGRY.BIOLUM.VDR2.3 Bioluminescence, vdr level 2-3
OCA.OCNGRY.BIOLUM.VDR3.4 Bioluminescence, vdr level 3-4
OCA.OCNGRY.BIOLUM.VDR4.5 Bioluminescence, vdr level 4-5
OCA.OCNGRY.BIOLUM.VDR5.6 Bioluminescence, vdr level 5-6
OCA.OCNGRY.BIOLUM.VDR6.7 Bioluminescence, vdr level 6-7
OCA.OCNGRY.BIOLUM.VDR7.8 Bioluminescence, vdr level 7-8
OCA.OCNGRY.BIOLUM.VDR8.9 Bioluminescence, vdr level 8-9
OCA.OCNGRY.BIOLUM.VDR9.0 Bioluminescence, vdr level 9-10
OCA.OCNGRY.BEHSPE.FLT Flat
OCA.OCNGRY.BEHSPE.GTL Gentle
OCA.OCNGRY.BEHSPE.MOD Moderate
OCA.OCNGRY.BEHSPE.STP Steep
OCA.GPHY.MNEWBD.MIWBS.SLDRCK Miw-bottom sediments, solid rock
OCA.GPHY.MNEWBD.MIWBS.CLAY Miw-bottom sediments, clay
OCA.GPHY.MNEWBD.MIWBS.VCSESD Very coarse sand
OCA.GPHY.MNEWBD.MIWBS.CSESD Miw-bottom sediments, coarse sand
OCA.GPHY.MNEWBD.MIWBS.MDMSD Miw-bottom sediments, medium sand
OCA.GPHY.MNEWBD.MIWBS.FNESD Miw-bottom sediments, fine sand
OCA.GPHY.MNEWBD.MIWBS.VFNESD Miw-bottom sediments, very fine sand
OCA.GPHY.MNEWBD.MIWBS.VFNSLT Miw-bottom sediments, very fine silt
OCA.GPHY.MNEWBD.MIWBS.FNESLT Miw-bottom sediments, file silt
OCA.GPHY.MNEWBD.MIWBS.MDMSLT Miw-bottom sediments, medium silt
OCA.GPHY.MNEWBD.MIWBS.CSESLT Miw-bottom sediments, coarse silt
OCA.GPHY.MNEWBD.MIWBS.BLDS Boulders
OCA.GPHY.MNEWBD.MIWBS.COBLOS Cobbles, oyster shells
OCA.GPHY.MNEWBD.MIWBS.PBLSHE Pebbles, shells
OCA.GPHY.MNEWBD.MIWBS.SD.SHE Sand and shells
OCA.GPHY.MNEWBD.MIWBS.LND Miw-bottom sediments, land
OCA.GPHY.MNEWBD.MIWBS.NODAT No data
OCA.GPHY.MNEWBD.BTMRGN.SMH Bottom roughness, smooth
OCA.GPHY.MNEWBD.BTMRGN.MOD Bottom roughness, moderate
OCA.GPHY.MNEWBD.BTMRGN.RGH Bottom roughness, rough
OCA.GPHY.MNEWBD.CTRB.LW Low
OCA.GPHY.MNEWBD.CTRB.MDM Medium
OCA.GPHY.MNEWBD.CTRB.HGH High
OCA.GPHY.MNEWBD.IMTBUR.0 Impact burial, 0%
OCA.GPHY.MNEWBD.IMTBUR.0.10 Impact burial, 0-10%
OCA.GPHY.MNEWBD.IMTBUR.10.20 Impact burial, 10-20%
OCA.GPHY.MNEWBD.IMTBUR.20.75 Impact burial, 20-75%
OCA.GPHY.MNEWBD.IMTBUR.75 Impact burial, >75%
OCA.GPHY.MNEWBD.MIWBC.A Miw bottom category, a
OCA.GPHY.MNEWBD.MIWBC.B Miw bottom category, b
OCA.GPHY.MNEWBD.MIWBC.C Miw bottom category, c
OCA.GPHY.MNEWBD.MIWBT.A1 Miw bottom type, a1
OCA.GPHY.MNEWBD.MIWBT.A2 Miw bottom type, a2
OCA.GPHY.MNEWBD.MIWBT.A3 Miw bottom type, a3
OCA.GPHY.MNEWBD.MIWBT.B1 Miw bottom type, b1
OCA.GPHY.MNEWBD.MIWBT.B2 Miw bottom type, b2
OCA.GPHY.MNEWBD.MIWBT.B3 Miw bottom type, b3
OCA.GPHY.MNEWBD.MIWBT.C1 Miw bottom type, c1
OCA.GPHY.MNEWBD.MIWBT.C2 Miw bottom type, c2
OCA.GPHY.MNEWBD.MIWBT.C3 Miw bottom type, c3
OCA.LMT.MARTLB Maritime limit boundary
OCA.LMT.MARTAR Maritime area
OCA.LMT.RSDARA Restricted area
OCA.LMT.SWPARA Swept area
OCA.LMT.TRGARA Training area
OCA.LMT.OD Operator-defined
OCA.MMD.SUBCBL Submarine cable
OCA.MMD.SBMCRB Submerged crib
OCA.MMD.CNL Canal
OCA.MMD.FRD Ford Yes
OCA.MMD.LCK Lock Yes
OCA.MMD.OLRG Oil/gas rig Yes
OCA.MMD.OLRGFD Oil/gas rig field
OCA.MMD.PPELNE Pipelines/pipe
OCA.MMD.PLE Pile/piling/post Yes



Appendix G, Emergency Management

Hierarchy Description Supported
NATEVT.GEO.AFTSHK Aftershock Yes
NATEVT.GEO.AVL Avalanche Yes
NATEVT.GEO.EQKEPI Earthquake epicenter Yes
NATEVT.GEO.LNDSLD Landslide Yes
NATEVT.GEO.SBSDNC Subsidence Yes
NATEVT.GEO.VLCTHT Volcanic threat Yes
NATEVT.HYDMET.DRGHT Drought Yes
NATEVT.HYDMET.FLD Flood Yes
NATEVT.HYDMET.INV Inversion Yes
NATEVT.HYDMET.TSNMI Tsunami Yes
NATEVT.INFST.BIRD Bird infestation Yes
NATEVT.INFST.INSCT Insect infestation Yes
NATEVT.INFST.MICROB Microbial infestation Yes
NATEVT.INFST.REPT Reptile infestation Yes
NATEVT.INFST.RDNT Rodent infestation Yes
