Icon Retriever

Overview

This guide shows how to use the IconRetriever interface to retrieve icons for tactical symbols. The guide is organized into in three sections:

Usage

Icons in a symbol set are retrieved using an IconRetriever. The retriever’s job is to take the identifier for a symbol and construct a BufferedImage that contains the icon for that symbol. An IconRetriever implementation handles icons for a specific symbol set. This guide will discuss the MilStd2525IconRetriever, which creates icons for symbols in MIL-STD-2525C.

IconRetriever.createIcon takes two parameters: an icon identifier, and a list of retrieval parameters. The format of the identifier is defined by the symbol set. For example, the MilStd2525IconRetriever accepts a MIL-STD-2525C SIDC. The retrieval parameter list is optional.

The icon retriever must be configured with a path to a symbol repository. The retrieval path identifies a directory or ZIP file that contains icons for the MIL-STD-2525C symbol set. See the Tactical Symbol Usage Guide for more information on how to set up a symbol repository.

The following code creates an icon for the MIL-STD-2525C Special Operation Forces Drone Aircraft (SFAPMFQM–GIUSA):

// Create an icon retriever to fetch symbols from the World Wind server
IconRetriever retriever = new MilStd2525IconRetriever(MilStd2525Constants.DEFAULT_ICON_RETRIEVER_PATH);
BufferedImage icon = retriever.createIcon("SFAPMFQM--GIUSA", null);

The code above retrieves this image:

Parameters

Frame on
Fill on
Icon on
Frame on
Fill off
Icon on
Frame off
Fill on
Icon on
Frame off
Fill off
Icon on
Frame off
Fill on
Icon off

Retrieval parameters are specified as key/value pairs. Each icon retriever may support different parameters. MilStd2525IconRetriever supports the following parameters to control how the symbol is constructed:

Show Icon

Determines if the symbol will be created with an icon.

Show Frame

Determines if the symbol will be created with a frame.

Show Fill

Determines if the symbol will include a fill color.

Color

Fill color applied to the symbol. If the symbol is drawn with a frame, then this color will be used to fill the frame. If the symbol is not drawn with a frame, then the fill will be applied to the icon itself. The fill color has no effect if Show Fill is False.

Example

The following code creates an instance of the Drone Aircraft graphic with no fill:

AVList params = new AVListImpl();
params.setValue(SymbologyConstants.SHOW_FILL, false);

IconRetriever retriever = new MilStd2525IconRetriever(MilStd2525Constants.DEFAULT_ICON_RETRIEVER_PATH);
BufferedImage icon = retriever.createIcon("SFAPMFQM--GIUSA", params);

The icon retriever will return this image:

See gov.nasa.worldwindx.examples.symbology.IconRetrieverUsage for more usage examples.
